Spotless finish with no visible screws

Equipped with our pioneering SmartSense technology for increased reliability and unmatched user experience

Sensing range and flush timing can be adjusted with remote. One remote works for multiple systems.

Concealed type

Power : 230 V/AC, single phase for AS 07-IR(E) and 6VDC (four alkaline batteries) for AS 07-IR(B)

Solenoid valve, Flow control valve & Electronic system are located in the concealed box. All components are accessible from front for easy maintenance.

Aluminium die-casting front plate

Front plate dimensions : W 150 x H 150 x D 11 mm

Brass solenoid valve with piston valve technology. This is a marked improvement over traditional rubber diaphragm-type valves.

Solenoid Valve is removable and operates on 6VDC.

Sensing range and flush timing can be adjusted with remote*.

360° debris screen (filter) reduces the common problem of water running and flooding.

Non-corrosive & highly durable polycarbonate concealed box. Dimensions : W 130 x H 130 x D 72 mm.

Water inlet & outlet supply connections of 1/2″ B.S.P.

Integrated sensor and control circuit is completely sealed with resin to give moisture free life.

Brass water flow regulator valve allows water flow to be adjusted & turned-off as desired.
